Testo Digital Vane Probe With Bluetooth And Temperature Sensor


Brand: Testo

Model No: 0635 9571

Order Code: 0635 9571

Warranty: 1 Year

Stock Status : 2 - 4 Weeks


Price : $1,404.00 CAD

Testo Digital Vane Probe with Bluetooth is used to measure air velocity, volume flow, and air temperature. The readings are transmitted directly to a measuring instrument (sold separately) via Bluetooth, up to a distance of 65 feet (20m), making your measurements particularly convenient. The vane probe is equipped with a telescope, which can be extended to a maximum length of 39.4-inch (1m). The telescope's immersion depth is easy to read, even if visibility is poor, because of the high-contrast scaling. Use the vane probe with the compatible Testo multifunction measuring instrument (please order separately) to determine air velocity, volume flow, and air temperature. The vane probe has a measuring range of +0.6 to +50m/s and features maximum accuracy from 5m/s.

TECHNICAL DATA

 Temperature - NTC
 Measuring Range: -10 to 70°C
 Accuracy: ±1.8°C
 Resolution: 0.1°C

Velocity/Volume flow
 Measuring Range: 0.6 to 50m/s
 Accuracy:
±(0.2m/s + 1% of mv) (0.6 to 40m/s)
                      ±(0.2m/s + 2% of mv) (40.1 to 50m/s)
 Resolution: 0.1m/s

General Technical Data
 Storage Temperature: -20 to 60°C
 Operating Temperature: -5 to 50°C
 Length Probe Shaft: 230mm
 Diameter Probe Shaft: 16mm
 Probe Head Diameter 16mm
 Radio Range: 20m
 Dimensions: 790 x 50 x 40mm
 Weight: 425g

FEATURES

 The readings of the vane probe are transmitted to your measuring instrument via Bluetooth, up to a distance of 20m

 The vane probe is equipped with a telescope, which can be extended to a maximum length of 1m. The immersion depth is easy to read, even if visibility is poor, thanks to the high-contrast scaling

 The clearly structured measurement menu for volume flow enables the measuring instrument to be operated intuitively. The volume flow is precisely calculated thanks to convenient input of the size and geometry of the duct cross-section. Timed and multi-point mean calculation, average volume flow, current reading, and minimum/maximum values are displayed in the measuring instrument

INTELLIGENT CALIBRATION CONCEPT

 You will get exceptionally accurate measurement results with the digital vane probe because the measuring instrument makes measurement uncertainty a thing of the past. You only need to send the probe in for calibration - so the measuring instrument remains in continuous use.

APPLICATIONS

 Ventilation Ducts: Use the vane probe to carry out convenient measurements of air velocity and air temperature, even at locations that are difficult to access in ventilation ducts. If required, the vane probe with an extendable telescope and easy-to-read scaling can easily be extended to a total length of up to 2m using the telescope extension (please order separately). This also makes it possible to carry out measurements on large ventilation systems.

PACKING INCLUDES

 Digital Vane Probe (Ø16mm) with Bluetooth including Temperature Sensor
 Handle Adapter and Bluetooth Handle
 4 x AA Batteries
 Calibration Protocol

Accessories
